ActronAir Add On Cooling Systems

Actron Air logo
Diagram demonstrating Actron Air's upward expulsion of air in contrast to their competitors that exhaust air into a wall reducing efficiency
ActronAir add-on units have superior vertical discharge which results in improved air circulation around the outdoor unit when compared to their competitors, which improves it’s performance, especially on those scorching days!
Acron Air's add on cooling system unit

Single Phase

Indoor/Outdoor

Three Phase

Indoor/Outdoor

Actron Air SRA131A/SRC131C – Single Phase

Nominal Capacity (kW)
(low/med/high)		 Nominal Input Power
(low/med/high)		 Nominal EER
(low/med/high)		 Nett Capacity (kW)
(low/med/high)		 Nett Input Power (kW)
(low/med/high)		 Nett EER
(low/med/high)		 Airflow Indoor (l/s)
(low/med/high)		 Power Supply – (V/Ph/Hz) Outdoor Unit Rated Amps (AS/NZS3823.1.2) Outdoor Unit Full Load Amps (AS/NZS3823.1.2) Circuit Breaker Amps (Suggested)
 12.28/12.33/12.82  3.21/3.22/3.23  3.82/3.83/3.97  12.15/12.20(2)/12.65  3.34/3.35(2)/3.40  3.64/3.64/3.72  590/640/850  230V / 1Ph+N / 50Hz  14.4  23.1  32.0
Refrigerant Fans (Type x Number per unit)
Outdoor		 Outdoor Dimensions (mm)
H x W x D		 Indoor Dimensions (mm)
H x W x D		 Nominal Weight (kgs)
Outdoor/Indoor		 Field Pipe Size
Maximum Field Pipe Length Range – (m)		 Field Pipe Size
Liquid Pipe – mm (inch)		 Field Pipe Size
Gas Pipe – mm (inch)		 Sound Pressure Level (dBA)
Outdoor (low/high fan)		 Sound Power Level (dBA)
Outdoor (low/high fan)		 MEPS Certified
 R410a  Axial / 6 Pole External Rotor / Direct Drive x 2  990 x 1320 x 580 412 x1050 x340  135/27  0 – 60  9.52 (3/8)  19.05 (3/4)  50 / 52  67 / 69  Yes

Actron Air SRA151A/SRC151C – Single Phase

Nominal Capacity (kW)
(low/med/high)		 Nominal Input Power
(low/med/high)		 Nominal EER
(low/med/high)		 Nett Capacity (kW)
(low/med/high)		 Nett Input Power (kW)
(low/med/high)		 Nett EER
(low/med/high)		 Airflow Indoor (l/s)
(low/med/high)		 Power Supply – (V/Ph/Hz) Outdoor Unit Rated Amps (AS/NZS3823.1.2) Outdoor Unit Full Load Amps (AS/NZS3823.1.2) Circuit Breaker Amps (Suggested)
14.94/15.36/15.78 4.00/4.02/4.04 3.74/3.82/3.91 14.80(2)/15.20/15.60 4.14(2)/4.18/4.22 3.57/3.64/3.70 690/810/950  230V / 1Ph+N / 50Hz  14.4  23.9  32.0
Refrigerant Fans (Type x Number per unit)
Outdoor		 Outdoor Dimensions (mm)
H x W x D		 Indoor Dimensions (mm)
H x W x D		 Nominal Weight (kgs)
Outdoor/Indoor		 Field Pipe Size
Maximum Field Pipe Length Range – (m)		 Field Pipe Size
Liquid Pipe – mm (inch)		 Field Pipe Size
Gas Pipe – mm (inch)		 Sound Pressure Level (dBA)
Outdoor (low/high fan)		 Sound Power Level (dBA)
Outdoor (low/high fan)		 MEPS Certified
 R410a  Axial / 6 Pole External Rotor / Direct Drive x 2  990 x 1320 x 580 412 x1250 x340  136/30  0 – 60  9.52 (3/8)  19.05 (3/4)  50 / 52  67 / 69  Yes

Actron Air SRA171A/SRC171C – Single Phase

Nominal Capacity (kW)
(low/med/high)		 Nominal Input Power
(low/med/high)		 Nominal EER
(low/med/high)		 Nett Capacity (kW)
(low/med/high)		 Nett Input Power (kW)
(low/med/high)		 Nett EER
(low/med/high)		 Airflow Indoor (l/s)
(low/med/high)		 Power Supply – (V/Ph/Hz) Outdoor Unit Rated Amps (AS/NZS3823.1.2) Outdoor Unit Full Load Amps (AS/NZS3823.1.2) Circuit Breaker Amps (Suggested)
16.65/16.96/17.49 4.55/4.57/4.59 3.66/3.71/3.81 116.50(2)/16.80/17.30 4.70(2)/4.73/4.77 3.51/3.55/3.63 765/840/980  230V / 1Ph+N / 50Hz  20.2  30.7  40.0
Refrigerant Fans (Type x Number per unit)
Outdoor		 Outdoor Dimensions (mm)
H x W x D		 Indoor Dimensions (mm)
H x W x D		 Nominal Weight (kgs)
Outdoor/Indoor		 Field Pipe Size
Maximum Field Pipe Length Range – (m)		 Field Pipe Size
Liquid Pipe – mm (inch)		 Field Pipe Size
Gas Pipe – mm (inch)		 Sound Pressure Level (dBA)
Outdoor (low/high fan)		 Sound Power Level (dBA)
Outdoor (low/high fan)		 MEPS Certified
 R410a  Axial / 6 Pole External Rotor / Direct Drive x 2  1045 x 1460 x 580 412 x1250 x340  176/32  0 – 60  9.52 (3/8)  19.05 (3/4)  52 / 54  69 / 71  Yes

Actron Air SRA131A/SRC133C – Three Phase

Nominal Capacity (kW)
(low/med/high)		 Nominal Input Power
(low/med/high)		 Nominal EER
(low/med/high)		 Nett Capacity (kW)
(low/med/high)		 Nett Input Power (kW)
(low/med/high)		 Nett EER
(low/med/high)		 Airflow Indoor (l/s)
(low/med/high)		 Power Supply – (V/Ph/Hz) Outdoor Unit Rated Amps (AS/NZS3823.1.2) Outdoor Unit Full Load Amps (AS/NZS3823.1.2) Circuit Breaker Amps (Suggested)
12.12/12.33/12.92 3.03/3.04/3.07 4.00/4.06/4.21 12.20/12.20(2)/12.75 3.15/3.17(2)/3.23 3.81/3.85/3.95 590/640/850  400V / 3Ph+N / 50Hz 6.2  8.3  16.0
Refrigerant Fans (Type x Number per unit)
Outdoor		 Outdoor Dimensions (mm)
H x W x D		 Indoor Dimensions (mm)
H x W x D		 Nominal Weight (kgs)
Outdoor/Indoor		 Field Pipe Size
Maximum Field Pipe Length Range – (m)		 Field Pipe Size
Liquid Pipe – mm (inch)		 Field Pipe Size
Gas Pipe – mm (inch)		 Sound Pressure Level (dBA)
Outdoor (low/high fan)		 Sound Power Level (dBA)
Outdoor (low/high fan)		 MEPS Certified
 R410a  Axial / 6 Pole External Rotor / Direct Drive x 2  990 x 1320 x 580 412 x1050 x340  133/27  0 – 60  9.52 (3/8)  19.05 (3/4)  50 / 52  67 / 69  Yes

Actron Air SRA151A/SRC153C – Three Phase

Nominal Capacity (kW)
(low/med/high)		 Nominal Input Power
(low/med/high)		 Nominal EER
(low/med/high)		 Nett Capacity (kW)
(low/med/high)		 Nett Input Power (kW)
(low/med/high)		 Nett EER
(low/med/high)		 Airflow Indoor (l/s)
(low/med/high)		 Power Supply – (V/Ph/Hz) Outdoor Unit Rated Amps (AS/NZS3823.1.2) Outdoor Unit Full Load Amps (AS/NZS3823.1.2) Circuit Breaker Amps (Suggested)
14.33/14.66/15.08 3.85/3.86/3.87 3.72/3.80/3.90 14.20/14.50(2)/14.90 3.98/4.02(2)/4.05 3.57/3.61/3.68 690/810/950  400V / 3Ph+N / 50Hz 7.2 11.7  20.0
Refrigerant Fans (Type x Number per unit)
Outdoor		 Outdoor Dimensions (mm)
H x W x D		 Indoor Dimensions (mm)
H x W x D		 Nominal Weight (kgs)
Outdoor/Indoor		 Field Pipe Size
Maximum Field Pipe Length Range – (m)		 Field Pipe Size
Liquid Pipe – mm (inch)		 Field Pipe Size
Gas Pipe – mm (inch)		 Sound Pressure Level (dBA)
Outdoor (low/high fan)		 Sound Power Level (dBA)
Outdoor (low/high fan)		 MEPS Certified
 R410a  Axial / 6 Pole External Rotor / Direct Drive x 2  990 x 1320 x 580 412 x1250 x340  135/30  0 – 60  9.52 (3/8)  19.05 (3/4)  50 / 52  67 / 69  Yes

Actron Air SRA171A/SRC173C – Three Phase

Nominal Capacity (kW)
(low/med/high)		 Nominal Input Power
(low/med/high)		 Nominal EER
(low/med/high)		 Nett Capacity (kW)
(low/med/high)		 Nett Input Power (kW)
(low/med/high)		 Nett EER
(low/med/high)		 Airflow Indoor (l/s)
(low/med/high)		 Power Supply – (V/Ph/Hz) Outdoor Unit Rated Amps (AS/NZS3823.1.2) Outdoor Unit Full Load Amps (AS/NZS3823.1.2) Circuit Breaker Amps (Suggested)
16.85/17.26/17.68 4.37/4.44/4.49 3.86/3.89/3.94 16.70(2)/17.10/17.50 4.52(2)/4.61/4.67 3.69/3.71/3.75 765/840/980  400V / 3Ph+N / 50Hz 8.6 12.3  20.0
Refrigerant Fans (Type x Number per unit)
Outdoor		 Outdoor Dimensions (mm)
H x W x D		 Indoor Dimensions (mm)
H x W x D		 Nominal Weight (kgs)
Outdoor/Indoor		 Field Pipe Size
Maximum Field Pipe Length Range – (m)		 Field Pipe Size
Liquid Pipe – mm (inch)		 Field Pipe Size
Gas Pipe – mm (inch)		 Sound Pressure Level (dBA)
Outdoor (low/high fan)		 Sound Power Level (dBA)
Outdoor (low/high fan)		 MEPS Certified
 R410a  Axial / 6 Pole External Rotor / Direct Drive x 2  1040 x 1460 x 580 412 x1250 x340  174/32  0 – 60  9.52 (3/8)  19.05 (3/4)  52 / 54  69 / 71  Yes

Actron Air SRA201A/SRC203C – Three Phase

Nominal Capacity (kW)
(low/med/high)		 Nominal Input Power
(low/med/high)		 Nominal EER
(low/med/high)		 Nett Capacity (kW)
(low/med/high)		 Nett Input Power (kW)
(low/med/high)		 Nett EER
(low/med/high)		 Airflow Indoor (l/s)
(low/med/high)		 Power Supply – (V/Ph/Hz) Outdoor Unit Rated Amps (AS/NZS3823.1.2) Outdoor Unit Full Load Amps (AS/NZS3823.1.2) Circuit Breaker Amps (Suggested)
18.77/19.09/19.70 5.25/5.26/5.27 3.58/3.63/3.74 18.60(2)/18.90/19.50 5.42(2)/5.45/5.47 3.43/3.47/3.56 900/985/1120  400V / 3Ph+N / 50Hz 10.4 13.9  20.0
Refrigerant Fans (Type x Number per unit)
Outdoor		 Outdoor Dimensions (mm)
H x W x D		 Indoor Dimensions (mm)
H x W x D		 Nominal Weight (kgs)
Outdoor/Indoor		 Field Pipe Size
Maximum Field Pipe Length Range – (m)		 Field Pipe Size
Liquid Pipe – mm (inch)		 Field Pipe Size
Gas Pipe – mm (inch)		 Sound Pressure Level (dBA)
Outdoor (low/high fan)		 Sound Power Level (dBA)
Outdoor (low/high fan)		 MEPS Certified
 R410a  Axial / 6 Pole External Rotor / Direct Drive x 2  1040 x 1460 x 580 435 x 1355 x340  185/38  0 – 20| 0 – 60  9.52 (3/8) | 12.70 (1/2)  22.22 (7/8) | 22.22 (7/8)  52 / 54  69 / 71  Yes

Actron Air SRA231A/SRC233C – Three Phase

Nominal Capacity (kW)
(low/med/high)		 Nominal Input Power
(low/med/high)		 Nominal EER
(low/med/high)		 Nett Capacity (kW)
(low/med/high)		 Nett Input Power (kW)
(low/med/high)		 Nett EER
(low/med/high)		 Airflow Indoor (l/s)
(low/med/high)		 Power Supply – (V/Ph/Hz) Outdoor Unit Rated Amps (AS/NZS3823.1.2) Outdoor Unit Full Load Amps (AS/NZS3823.1.2) Circuit Breaker Amps (Suggested)
22.28/23.22/23.89 5.95/6.00/6.03 3.74/3.87/3.96 22.10(2)/23.00/23.65 6.14(2)/6.21/6.28 3.60/3.70/3.77 980/1200/1400  400V / 3Ph+N / 50Hz 12.0 15.9  25.0
Refrigerant Fans (Type x Number per unit)
Outdoor		 Outdoor Dimensions (mm)
H x W x D		 Indoor Dimensions (mm)
H x W x D		 Nominal Weight (kgs)
Outdoor/Indoor		 Field Pipe Size
Maximum Field Pipe Length Range – (m)		 Field Pipe Size
Liquid Pipe – mm (inch)		 Field Pipe Size
Gas Pipe – mm (inch)		 Sound Pressure Level (dBA)
Outdoor (low/high fan)		 Sound Power Level (dBA)
Outdoor (low/high fan)		 MEPS Certified
 R410a  Axial / 6 Pole External Rotor / Direct Drive x 2  1105 x 1685 x 685 485 x 1405 x 340  200/41  0 – 60  12.70 (1/2) 25.40 (1)  55 / 58  71 / 75  Yes
Actron Air add on cooling system brochure

Actron Air Add-On Cooling Brochure
